Description Camera Image Sensor 2 MP CMOS Signal System PAL/NTSC Resolution 1920 (H) × 1080 (V) Frame Rate TVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC Min. illumination 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s Field of View Horizontal FOV: 79.6°, Vertical FOV: 43.5°, Diagonal FOV: 93.7° Lens Mount M12 Day & Night ICR WDR (Wide Dynamic Range) Digital WDR Audio Built-in Microphone Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360° Menu Image Mode STD/HIGH-SAT AGC Yes Day/Night Mode Auto / Color / BW (Black and White) White Balance Auto/Manual AE (Auto Exposure) Mode D-WDR / BLC / HLC / Global Noise Reduction 2D DNR Language English Function Brightness, Sharpness, Mirror, Smart IR Interface Video Output Switchable TVI / AHD / CVI / CVBS General Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) Power Supply 12 VDC ± 25% Power Consumption Max. 2.7 W Protection Level IP67 Material Plastic IR Range Up to 25 m Communication HIKVISION-C Dimensions 58 mm × 61 mm × 158.6 mm (2.28″ × 2.40″ × 6.42″) Weight Approx. 160 g (0.35 lb.)
