Description Camera Image Sensor 2 MP CMOS Signal System PAL/NTSC Resolution 1920 (H) × 1080 (V) Frame Rate TVI: 1080p @25fps/30fps CVI: 1080p @25fps/30fps AHD: 1080p @25fps/30fps CVBS: PAL/NTSC Min. Illumination 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s Field of View 2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115° 3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90° Lens Mount M12 Light Alarm Solid Light Alarm (White Light) WDR (Wide Dynamic Range) Digital WDR Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° Menu White Light Auto/Off Image Mode STD / HIGH-SAT / HIGHLIGHT AGC Yes Day/Night Mode Color White Balance Auto/Manual AE (Auto Exposure) Mode DWDR, BLC, HLC, Global Noise Reduction 3D DNR/2D DNR Language English Function Brightness, Mirror, Sharpness, Anti-Banding, Smart Light Interface Video Output Switchable TVI/AHD/CVI/CVBS General Operating Conditions -40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing) Power Supply 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. Consumption Max. 2.4 W Material Plastic White Light Range Up to 20 m Communication HIKVISION-C Dimension Φ 85.02 mm × 81.25 mm (Φ 3.35″ × 3.2″)
